EAA coated Steel Wire
EAA (Ethylene Acrylic Acid) coated steel wire have been specially developed for the Fiber to the home (FTTX) cables,
it has memory free Steel Wire with very low bend radius and good adhesion to all types of jacket material.
These are used as reinforcement embedded in PE/PVC/LSHF jacket material.
Suitable for produce very low bend radius drop cable, FTTX cable and figure 8 cables.
Long continuous lengths with very close diameter tolerances make it enable to increase productivity.
Our Coated Steel Wires are memory free and easily adapt to mechanical stresses.
Our EAA coated and high strength steel wire is especially suited for FTTx cable applications, used to the optical fiber cables to make sure the steel wire and outer sheath more tightly (anti-relative displacement).
Wire Size Range: 0.33 mm – 2.40 mm (after coating)
Coating thickness (one side): 0.05mm, Other coating thickness can be customized.
Steel Wire core: Phosphated steel wire or Galvanized steel wire, according to request.
EAA model: Dow Chemical, Model: 3004 or Dupont Company, Model: 2002
Capacity: 40 tons per month.
